Formax Cut-True 28A Programmable Automatic Guillotine Cutter
The Formax Cut-True 28A Electric Guillotine Paper Cutter offers precision cutting for paper stacks up to 18.9” wide. User-friendly, intuitive features include a touchscreen control panel, automatically adjusting back gauge, and the capacity to program up to 99 jobs with up to 30 cuts each. An infrared light beam safety curtain provides safety and convenience, shutting down operation if the light plane is interrupted.
Operation is simple: utilize the touchscreen control panel to program and select job settings, then load a stack of paper up to 3.15” high. Set the back gauge using the touchscreen., and the electronic fine-adjustment knob. The bright LED Cutting Line lets operators see where the blade will cut and make fine adjustments. Electronically-controlled two-hand operation engages the hardened steel blade for crisp, accurate cuts every time.
Standard safety features include a wooden paper push for safe alignment, a lock with key, a blade lock, external blade depth adjustment, automatic blade return from any position, and an easy-to-use blade change safety tool. The Cut-True 28A is ideal for transforming large sheets into brochures, invitations, and more, with crisp, accurate cuts, and is a welcome addition to print shops and in-plant finishing operations.
Features:
- Standard 110-volt power
- Programmable Touchscreen control panel
- Electronic two-button operation
- Automatic paper clamp and back gauge
- Infrared Safety Curtain
- Cuts stacks up to 18.9" W, 3.15" H
- Program up to 99 jobs
Specifications:
- Cutting Action Dual-button electric
- Maximum Cutting Width 18.9” (480mm)
- Maximum Paper Stack Height 3.15” (80mm)
- Cutting Length Behind Blade 18.9” (480mm)
- Table Size in Front of Blade 32” W x 37” D (811 x 941mm)
- Narrow Cut 1.37” (35mm)
- LED Cutting Line Yes
- Clamp Style Automatic
- Back Gauge Adjustment Touchscreen or electronic hand wheel
- Back Gauge Reading Color touchscreen, in both standard and metric
- Programmable Jobs Up to 99, with up to 30 cuts
- Blade Change Safety Tool Included
- Dimensions 60” H x 36” W x 40” D (1520 H x 920 W x 1010mm D)
- Weight 575 lbs (260kg)
- Power Supply 110V, 20A dedicated line
- Safety Certifications UL-approved
