Intimus 16.50 10x70 Heavy Duty Industrial Shredder With Conveyor
The intimus 16.50 SmartShred is a robust, industrial document shredder with a feed conveyor belt and a large 450-litre mobile collection container. The shredder has a user-friendly touchscreen with a programmable logic controller (PLC). This enables, for example, language selection, recording of operating hours, display of all machine processes, precise error display, or maintenance reminders, thus speeding up maintenance. An extensive emergency stop bar on the input table ensures immediate cessation in emergencies.
Its spacious 500 mm working width enables convenient and fast loading and efficiently shreds all types of paper materials: loose, stapled, bound, crumpled, and even entire folders and books. Small quantities of plastic materials such as credit cards, CDs, and floppy disks can also be shredded. Its cutting width of 10 x 70 mm complies with security level P-2. An auto-reverse function ensures that paper jams caused by overloading are cleared quickly, and a fill level sensor stops the machine automatically as soon as the container is full. The shredder is equipped with a standard intelligent automatic oiler.
Features
- The 10 x 70 mm particles comply with security standard P-2, which is based on DIN 66399 (ISO/IEC 21964).
- Compatible with all types of paper materials - loose, stapled, bound, or crumpled - as well as entire folders, books, and small quantities of plastic materials such as credit cards, CDs, and floppy disks.
- Efficiently processes 400-450 sheets of 80 g/m² paper at a working width of 500 mm, ensuring fast and effective document processing.
- It guarantees smooth operation with a high throughput of around 600 kg per hour.
- Equipped with a robust metal housing and mobile collection container for added convenience.
- Induction-hardened, nitrocarburised solid steel cutting cylinders/shafts ensure durability and a long service life.
- Features an intuitive touch display with programmable logic control (PLC).
- An emergency stop bar, switch, and lockable main switch are needed for added safety.
- It enables effortless document shredding with a high-capacity conveyor belt, automatic return, overload protection, bin full sensor, and automatic oiler.
Specifications
|
Area of application
|
Industrial
|
|
Cutting size paper (mm x mm)
|
10 x 70
|
|
Cutting type paper
|
Crosscut
|
|
Security level ISO/IEC 21964 (DIN 66399)
|
P-2 / T-21 / O-2 / E-23
|
|
Shredding material
|
Paper with staples and paper clips, Crumpled paper, CD / DVD / Blu-ray, Plastic card, Folder, Floppy disk
|
|
Material cutting cylinders/shaft
|
Induction-hardened, nitrocarburized solid steel
|
|
Waste disposal solution
|
Mobile collection container
|
|
Intake width (mm)
|
500
|
|
Inlet/desk height (mm)
|
1.200
|
|
Sheet capacity (80g/m²)
|
400 - 450
|
|
Throughput
|
approx. 600 kg/h
|
|
Cutting speed (80g/m²) mm/s
|
240
|
|
Bin volume (l)
|
450
|
|
Continuous Running
|
yes
|
|
Noise level (idle operation) dB(A)
|
61
|
|
Motor protection device with thermal sensor
|
yes
|
|
Power supply (V / Hz)
|
400 / 50
|
|
Other voltages available
|
yes
|
|
Product dimensions W x D x H (cm)
|
121 x 195 x 163
|
|
Product weight (kg)
|
726
|
|
Control operation
|
Touch display
|
|
Visual status indication for ...
|
All activities and issues are shown on display and information e.g. overall operation time, blockages
|
|
Auto reverse
|
yes
|
|
Internal conveyor belt
|
yes
|
|
Hour meter
|
yes
|
|
Overload protection
|
yes
|
|
Safety features
|
Emergency stop bar, Transparent plastic curtain in the feeding area
|
|
Lockable master switch
|
yes
|
|
Bin full sensor
|
yes
|
|
Dust extractor
|
optional
|
|
Expansion of feed table
|
optional
|
|
Material machine housing
|
Metal
|
|
Made in Germany
|
yes
|
|
Certificates / Listings
|
CE, UKCA
|
|
