MBM Foilglazer II Laminator and Foil Fuser
The MBM Laminator and Foil Fuser, Foilglazer II, is a compact and robust laminating and foil-fusing machine designed for digital short-run jobs. It accommodates paper sizes up to 14.3” x 23.6” and features an easy-to-use 4.3” color touch screen with an inching switch and pressure roller lifting lever. The automatic air suction feeding system ensures consistent feeding for various prints, including stocks from 110 gsm to 400 gsm and various laminating films. Ideal for on-demand foil fusing, it works with any color foil rolls on black toners to enhance digital prints. The Foilglazer II offers intuitive operation, and the maximum speed for laminating is 16.4' /min and 9.84'/min for the Foilglazing, and an automatic film cutting mechanism for efficient, hands-free operation.
Features
• Speed: Laminating: 16.4’/min.
• Speed: Foilglazing: 9.84’/min.
• Sheet Capacity: 2″ Stack
• Paper Weight: 110 – 400 gsm* (32lb bond – 150lb cover
• Paper Size: Laminating: 11.69” x 8.26” – 14.37” x 23.62”
• Paper Size Foilglazing: 5.82” x 8.26” – 14.37” x 23.62”
Specifications
• Item #: CU0484
• Electrical Requirements: 100-120 V, 50/60 Hz
• Dimensions (D x W x H): 22.9″ x 24.45″ x 47.48″
• Dimensions with table: 67.6″ x 24.45″ x 47.48″
• Weight: 254lbs.
Notes:
***The FoilGlazer II Does Not Come with an Air Compressor.
( MBM uses the Kobalt Quiet Tech Compressor 2 Gallon, which costs around $200 in 2025 )
( 1 Gallon Minimum and 2 Gallon Max required to fit underneath. )
( External Sources can be used, but the unit needs 90 PSI )
( 6mm outside diameter tube on the unit )( 1/4 inch is standard, so that you can buy an adapter on Amazon or at your local Parts Store )
( Compressor runs about 60 Decibels, but does not always run. )
