MBM Triumph VRCUT 5560 Cutter

MBM Triumph VRCUT 5560 Cutter

VRCut is a groundbreaking PC software solution designed to automate the cutting workflow by promoting an efficient and error-free cutting process from start to finish. VRCut intelligently bridges the gap between pre-press and the finishing process, allowing operators of any experience level to cut with confidence on select Triumph cutters.

Two modules, one integrated workflow: The VRCut solution consists of two independent modules that work together. The Impose module creates PDF documents explicitly formatted to work with the VRCUT Controller module. The Controller module connects directly to the Triumph cutter, moving the back gauge and visually guiding operators through the cutting sequence.

Features

• Programmable cutter with hydraulic blade and clamp drive, power back gauge, digital touchpad
• Electric back gauge drive with touchpad for easy programming
• Digital measurement display (cm or inches) with multilingual operator guidance, accurate to 1/10 mm or 1/100 inch
• Stores 99 programs with up to 99 steps in each (up to 15 repeat cuts can be integrated as a single step)
• Pre-programmed for standard paper sizes
• Memory key for repeat cuts
• Automatic set function for reference measurement and eject function for pushing out paper
• Self-diagnostic system with error indication on display
• Electronic back gauge control with variable speed control for manual back gauge setting
• 5560 LT model equipped with front and rear air tables (available by special order only)
• Foot pedal for pre-clamping
• Clamp pressure is fully adjustable between 1,900 and 3,800 psi
• False clamp plate. Bright, LED optical cutting line
• Stainless steel work surface
• High-quality, German HSS blade
• Precision swing cut blade movement
• Aluminum blade carrier and clamp bar
• Adjustable blade guides
• All-metal construction
• Mounted on casters
• Includes an easy-access tool holder and paper-blocking tool
• Optional side tables increase the work surface
• UL and C UL approved

Safety Features

• Comprehensive SCS safety package: Patented easy-cut electronic blade activation bars for true two-hand operation
• IR light beam safety curtain on the front table
• Safety cover on rear table
• Main switch and safety lock with key
• 24-volt controls (low voltage)
• Patented IDEAL safety drive
• Automatic blade and clamp return from every position
• Disc brake for instant blade stop
• Blade changing device covers the cutting edge of the blade
• Blade depth adjustment from outside of the machine
• Blade and cutting stick can be changed without removing covers
